Product Specifications

B93 Series Signage MonitorDifference contrast

Model 98B93K 86B93K 75B93K 65B93K

Panel size 98" 86" 75" 65"

Display parameters Backlight category DLED DLED DLED DLED
Optimum resolution 3840*2160@60Hz 3840*2160@60Hz 3840*2160@60Hz 3840*2160@60Hz
Viewing angle H:178°/V:178° H:178°/V:178° H:178°/V:178° H:178°/V:178°
Brightness 500cd/m² 450cd/m² 450cd/m² 400cd/m²
Contrast ratio 1200:1 1200:1 1200:1 1200:1
Response time 8ms 8ms 8ms 8ms
Color 1.07B 1.07B 1.07B 1.07B
Color Gamut 72%(typ)NTSC 72%(typ)NTSC 72%(typ)NTSC 72%(typ)NTSC

Electrical Parameters Power Consumption ≤420W(Without OPS) ≤380W(Without OPS) ≤300W(Without OPS) ≤170W(Without OPS)
Standby Power Consumption ＜0.5W ＜0.5W ＜0.5W ＜0.5W
Operating voltage AC 100V~240V, 50/60Hz AC 100V~240V, 50/60Hz AC 100V~240V, 50/60Hz AC 100V~240V, 50/60Hz

Structure Parameters Product Dimension(W*D*H) 2204.85mm*101.7mm*1260.35mm 1937.8mm*79.6mm*1108.8mm 1692.5mm*79.6mm*970.7mm 1476.7mm*79.8mm*851.7mm
Packing dimension(W*D*H) 2525mm*435mm*1750mm 2125mm*275mm*1275mm 1880mm*245mm*1125mm 1660mm*245mm*1045mm
Speaker 2×5W/8Ω 2×5W/8Ω 2×5W/8Ω 2×5W/8Ω

Motherboard solution Chip solution MSD3683、T982(Optional) MSD3683、T982(Optional) MSD3683、T982(Optional) MSD3683、T982(Optional)

System System version Android 13、Windows(Optional) Android 13、Windows(Optional) Android 13、Windows(Optional) Android 13、Windows(Optional)

Model 55B93K 43B93K 110B93K

Panel size 55" 43" 110"

Display parameters Backlight category DLED DLED DLED
Optimum resolution 3840*2160@60Hz 3840*2160@60Hz 3840*2160@60Hz
Viewing angle H:178°/V:178° H:178°/V:178° H:178°/V:178°
Brightness 350cd/m² 350cd/m² 500cd/m²
Contrast ratio 1200:1 1200:1 1200:1
Response time 8ms 8ms 8ms
Color 1.07B 1.07B 1.07B
Color Gamut 72%(typ)NTSC 72%(typ)NTSC 72%(typ)NTSC

Electrical Parameters Power Consumption ≤140W ≤85W ≤180W
Standby Power Consumption ＜0.5W ＜0.5W ＜0.5W
Operating voltage AC 100V~240V, 50/60Hz AC 100V~240V, 50/60Hz AC 100V~240V, 50/60Hz

Structure Parameters Product Dimension(W*D*H) 1243.2mm*69.6mm*714mm 969.6mm*84.8mm*558.3mm 2512.3mm*138.7mm*1443.7mm
Packing dimension(W*D*H) 1364mm*154mm*824mm 1070mm*153mm*663mm 2800mm*435mm*1900mm
Speaker 2×5W/8Ω 2×5W/8Ω 2×5W/8Ω

Motherboard solution Chip solution MSD3683、T982(Optional) MSD3683、T982(Optional) MSD3683、T982(Optional)

System System version Android 13、Windows(Optional) Android 13、Windows(Optional) Android 13、Windows(Optional)

Remarks: KTC will provide the information as correct as possible. Product photos on this website may vary from the real products. Products information may vary from the products manual available in the market. Please use the products subjected to the specific information on the user manual. For details, please contact the related persons.
