Digital Calendar
-
-
Model
156TR1FDT
-
Electric Parameters
CPU
RK3326
-
Trumpet
2*2.5W
-
RAM
2GB
-
ROM
32GB
-
WIFI
802.11b/g/n
-
Software
Software version
Android 8.0
-
External port
USB-A
USB Drive Connection
-
DC-IN
12V 2A
-
Type-C
OTG upgrade
-
Expansion
SD card slot(MAX 128GB)
-
EARPHONE
Headphone Jack
-
Touch
Support multi touch
5-touch supported
-
Structure
Rotate
90° vertical rotation,90° automatic portrait‑landscape rotation
-
Usage
Desktop placement,Wall‑mount placement
-
Display parameters
Screen type
E-LED
-
Resolution
1920*1080
-
Brightness
280cd/m²
-
Aspect ratio
16:9
-
Contrast ratio
1000:1
-
Colour gamut(NTSC)
45%(Typ)NTSC
-
Viewing angle
178°(H) / 178°(V）
-
Color
16.7M(6bit+2FRC)
-
Dimensions parameters
Bare machine dimensions(W*D*H)
387.7×237.1×23.5mm
Remarks: KTC will provide the information as correct as possible. Product photos on this website may vary from the real products. Products information may vary from the products manual available in the market. Please use the products subjected to the specific information on the user manual. For details, please contact the related persons.
