Digital Frame
-
-
Model
156TX2YKT
-
Electric Parameters
CPU
RK3326S
-
Trumpet
2*2W
-
RAM
2GB
-
ROM
32GB
-
WIFI
2.4G WIFI6 802.11b/g/n/ax
-
Software
Software version
Android 8.0
-
External port
USB-A
OTG upgrade
-
DC-IN
12V/2A
-
Type-C
Download program
-
Expansion
SD card slot(MAX 128GB)
-
Touch
Support multi touch
10-touch supported
-
Structure
Rotate
90° vertical rotation,90° automatic portrait‑landscape rotation
-
Usage
Desktop placement,Wall‑mount placement
-
Display parameters
Screen type
E-LED
-
Resolution
1920*1080
-
Brightness
250cd/m²
-
Aspect ratio
16:9
-
Contrast ratio
1100:1
-
Colour gamut(NTSC)
45%(Typ)NTSC
-
Viewing angle
178°(H) / 178°(V）
-
Color
16.7M(6bit+2FRC)
Remarks: KTC will provide the information as correct as possible. Product photos on this website may vary from the real products. Products information may vary from the products manual available in the market. Please use the products subjected to the specific information on the user manual. For details, please contact the related persons.
