Product Specifications
SAMSUNG
  •
  •   Model 46D17-SL
  •   Panel size 46"
  • Display parameters Backlight category DLED
  •   Optimum resolution 1920*1080@60Hz
  •   Viewing angle H:178°/V:178°
  •   Brightness 500cd/m²
  •   Contrast ratio 4000:1
  •   Response time 8ms
  •   Color 16.7M
  •   Joint 1.7mm
  • Power waste Power ≤135W
  •   Operating voltage 100V-240VAC 60/50Hz
  • Specifications Bare dimension 1020.02mm*125.7mm*574.71mm
  •   Packing dimension 1145mm*215mm*698mm
  •   N.W. TBD
  •   G.W. TBD
  •   Shell material Sheet metal
  • Input interface HDMI 1
  •   VGA 1
  •   DVI 1
  •   RS232 1
  •   USB 2
  •   AUDIO IN-L(RCA)/IN-R(RCA) 1
  •   PC AUDIO 1
  •   AV(BNC) 4
  •   Y/Pb/Pr(BNC) 1
  •   SV-Y/SC-C(BNC) 1
  • Output interface AV(BNC) 1
  •   RS232 1
  •   AUDIO OUT-L(RCA)/OUT-R(RCA) 1
Remarks: KTC will provide the information as correct as possible. Product photos on this website may vary from the real products. Products information may vary from the products manual available in the market. Please use the products subjected to the specific information on the user manual. For details, please contact the related persons.
