TV
-
-
Model
77S2
-
Display parameters
Backlight category
OLED
-
Aspect ratio
16:9
-
Resolution
3840*2160
-
Visible area
1722.7mm*987.1mm
-
Viewing angle
H:120°/V:120°
-
Color
1.07B
-
Typical Brightness
640cd/m²
-
Contrast ratio
1500000:1
-
Response time
0.1ms
-
Power waste
Power
≤600W
-
Operating voltage
100V-240V AC 60/50Hz
-
Audio Power output
15W*2+10W*2+20W*1 (GTV3.0)
15W*2+20W*1 (AOSP)
-
Specifications
N.W.
41.96kg
-
G.W.
53.49kg
-
Product dimension(Without Base)
1722.7mm×53.4mm×997.7mm(Without Base)
-
Interface type
Input interface
HDMI/VGA/AV-IN/TV/USB/USB2.0/YPbPr/PC-Audio/Audio-IN/SERVICE/Tuner/RJ-45/CI(The above interface is optional according to the scheme)
-
Output interface
Earphone/Audio-OUT/Video-OUT/Coaxial-OUT/SPDIF-OUT(The above interface is optional according to the scheme)
-
USB support
Video/Audio/Image
-
Packing list
TV
1
-
Base
1(optional)
-
Wall bracket
1(optional)
-
Remote control
1
-
Power cord
1
-
Instructions
1
Remarks: KTC will provide the information as correct as possible. Product photos on this website may vary from the real products. Products information may vary from the products manual available in the market. Please use the products subjected to the specific information on the user manual. For details, please contact the related persons.
