PAD
-
-
Model
8T11YDT
-
Structure specification
Structure composition
Full lamination: OC+TP+tempered glass
-
Lamination process
Full lamination
-
Whole machine size
213mm*8.3mm*124.7mm
-
Surface treatment
AG+AF
-
Optical Specification
A-A
8.68 inch
-
Resolution
1340*800
-
Aspect ratio
16:9
-
Backlight category
ELED
-
Resfresh rate
60Hz
-
Response time
30ms
-
Module Color Gamut
60%
-
Color
16.7M
-
Brightness uniformity(9P)
-
Machine brightness
350cd/m²
-
Tempered Glass Light Transmission
-
Contrast Ratio
1000:1
-
Electrical Specifications
TP
-
Overall power
-
Touch Panel
10-point multi-touch supported
-
Speakers
1W*2
-
Key
Power, Volume +，Volume -
-
Mainboard Interface
Type-C*1
-
Power source
-
Chipset
MT8768/MT8385
-
CPU
Cortex-A53*8/Cortex-A53*4+A73*4
-
RAM+ROM
4GB+64GB(6GB+128GB)
-
System Version
Android 13/Android 12
-
Microphone
2*MIC
-
WIFI
WIFI 5
-
Bluetooth
2.1+EDR/4.2/5.0
-
Batteries
4500mAh
-
Power Supply
Type-C,≤20W
-
Camera
The structure and electrical system of this device have been made compatible
Remarks: KTC will provide the information as correct as possible. Product photos on this website may vary from the real products. Products information may vary from the products manual available in the market. Please use the products subjected to the specific information on the user manual. For details, please contact the related persons.
