Product Specifications
SAMSUNG
  •
  •   Model 46D43-H
  •   Panel size 46"
  • Display parameters Backlight category DLED
  •   Optimum resolution 1920*1080@60Hz
  •   Viewing angle H:178°/V:178°
  •   Brightness 700cd/m²
  •   Contrast ratio 3500:1
  •   Response time 8ms
  •   Color 16.7M
  •   Joint 3.7mm
  • Power waste Power ≤165W
  •   Operating voltage 100V-240VAC 60/50Hz
  • Specifications Bare dimension 1022mm*120.7mm*576.6mm
  •   Packing dimension 1223mm*681mm*896mm
  •   N.W. 27.2kg
  •   G.W. 38.7kg
  •   Shell material Blister
  • Input interface HDMI 1
  •   VGA 1
  •   DVI 1
  •   RS232 1
  •   USB 2
  •   PC AUDIO 1
  •   AUDIO IN-L(RCA)/IN-R(RCA) 1
  •   AV(BNC) 4
  •   Y/Pb/Pr(BNC) 1
  •   SV-Y/SC-C(BNC) 1
  • Output interface AV(BNC) 1
  •   RS232 1
  •   AUDIO OUT-L(RCA)/OUT-R(RCA) 1
Remarks: KTC will provide the information as correct as possible. Product photos on this website may vary from the real products. Products information may vary from the products manual available in the market. Please use the products subjected to the specific information on the user manual. For details, please contact the related persons.
